BRUNIMIND NG PCB Inspection Buffer
Key Features
- Integrated cooling function, customizable for specific production needs
- 4 selectable pitches for adjustable PCB feeding step distance
- User-friendly membrane control panel for simple operation
- Durable roller transmission system, no belt replacement required
- Three flexible operation modes: FIFO, LIFO, Pass-through
- Parallel smooth width adjustment via leadscrew for precise PCB fitting
- Fast, smooth and accurate PCB position retrieval
- Fully enclosed design for maximum operational safety
- Compact footprint, ideal for space-constrained SMT production areas
- Standard SMEMA compatible for seamless SMT line integration
Product Description
BRUNIMIND NG PCB Inspection Buffer is an intelligent automated SMT equipment engineered for the critical inspection and testing stages of PCB production lines. Specialized in separating rejected (NG – No Good) and qualified (OK) PCBs, it provides reliable temporary buffering and precise sorting, ensuring unobstructed and efficient flow of the entire SMT production line.
Installed directly after AOI (Automatic Optical Inspection) or SPI equipment, this buffer automatically receives quality detection signals and routes PCBs to the corresponding output paths: OK PCBs continue to subsequent production processes, while NG PCBs are buffered for manual inspection and rework. With fully automated operation and SMEMA-compatible interfaces, it eliminates the need for manual PCB sorting, reduces human error, and strengthens overall quality control for electronic manufacturing.
Technical Specifications
| Item | Details |
|---|---|
| Application | PCB storage & delivery after AOI/SPI equipment; NG/OK PCB sorting & buffering |
| Cycle Time | Approx. 10 seconds |
| Max. PCB Storage Capacity | 15pcs (fully customizable) |
| Power Supply | AC 110/220 volts; single phase |
| Max. Power | 250VA |
| Transport Height | 900 ± 20 mm (customizable) |
| Transport Direction | Left to Right / Right to Left (bidirectional) |
| Selectable Pitches | 4 types (for adjustable PCB step distance) |
| Operation Modes | FIFO, LIFO, Pass-through |
Key Applications
- Post-AOI/SPI/ICT sorting: Precisely separates NG PCBs from OK PCBs for rework and defect analysis
- NG PCB buffering: Temporarily stores defective PCBs for professional technician inspection
- SMT production line flow management: Automatically handles inspection results to ensure uninterrupted line operation
- Electronic manufacturing quality control: Enhances defect tracking and minimizes PCB handling errors
- High-speed SMT lines: Maintains production efficiency by integrating seamless sorting and buffering
Usage Benefits
- Automatically sorts NG/OK PCBs without halting production, maximizing SMT line uptime
- Reduces manual labor and human error in the PCB inspection and sorting process
- Improves production quality assurance and defect traceability for better QA management
- Prevents defective NG PCBs from entering subsequent production processes, reducing rework costs
- Durable roller transmission requires no belt replacement, lowering equipment maintenance costs
- Compact design saves valuable factory floor space, suitable for all SMT production layouts
- Customizable capacity and transport height, adaptable to diverse production requirements
- SMEMA compatibility enables easy integration with existing SMT line equipment, no complex reconfiguration
