PCB Stacker and Magazine Combination Loader | Dual-Mode SMT Loader | Brunimind

Brunimind dual-mode PCB stacker & magazine combination loader for SMT lines—SMEMA compatible, 400pcs capacity, zero PCB breakage. Save space & cost for your PCB assembly line.

PCB Stacker and Magazine Combination Loader

Product Description

Brunimind PCB Stacker and Magazine Combination Loader is an advanced dual-mode SMT loading system designed for PCB assembly lines that need frequent switching between bare board stacking and magazine-style feeding.As a standard SMEMA compatible PCB loader, it supports a maximum storage capacity of 400 pieces for 0.6mm thickness boards. The specially designed pneumatic structure and protection system ensure zero PCB damage during operation.This integrated dual-mode design helps PCB manufacturers save equipment space, reduce investment costs, and improve production efficiency for both small-batch and mass production lines.

Features

  • Dual-mode design: supports stacking loading and magazine loading
  • Fully SMEMA compatible, easy to integrate with all SMT production lines
  • Stable pneumatic control system, effectively preventing PCB scratch and breakage
  • High storage capacity up to 400pcs (0.6mm PCB)
  • Adjustable PCB width and height for various board sizes
  • User-friendly control panel, simple operation and maintenance
  • Safe and reliable structure, low failure rate
  • Supports global voltage: AC 110V / 220V

Technical Specifications

  • Model: Customizable according to production requirements
  • Loading Type: Stacker + Magazine dual-mode
  • PCB Capacity: Max 400pcs (0.6mm thickness)
  • PCB Thickness: 0.6–5.0mm
  • Control System: PLC + touch screen
  • SMEMA Interface: Standard compatible
  • Working Voltage: AC110V/220V (optional)
  • Air Pressure: 0.5–0.7 MPa
  • Application: PCB assembly, SMT production lines, electronic manufacturing

Applications

This dual-mode combination loader is widely used in PCB processing, SMT production lines, electronic assembly plants, and various automated production lines that require flexible and stable PCB loading. It is suitable for mass production, multi-specification production switching, and automated upgrading of production lines.

Advantages

  • Dual-mode structure reduces the need for multiple machines, saving space and cost
  • High-efficiency loading improves the overall operation efficiency of the production line
  • Stable transmission structure protects PCB from damage and reduces production loss
  • Flexible adjustment for different PCB sizes
  • Easy to install, operate and maintain
  • Long service life and stable performance

FAQ

  1. Is this loader compatible with SMEMA?Yes, it uses standard SMEMA signal interface and can be connected seamlessly with other SMT equipment.

  2. What is the maximum PCB storage capacity?It can hold up to 400 pieces of 0.6mm thick PCB.

  3. Can the PCB width and height be adjusted?Yes, you can adjust the parameters easily through the control panel to fit different PCB sizes.

  4. Does it protect PCBs from damage?Yes, the pneumatic structure and buffer design greatly reduce PCB scratches, collisions and damages.

  5. What voltage does this machine support?It supports AC110V and AC220V, suitable for global industrial use.
